OT-4XX INDICATOR OXYGEN (O₂) TRANSMITTER

  • NG # 0532230-HW-EMS-230

OT-4XX Oxygen (O₂) Transmitter with Display provides precise oxygen monitoring with clear local indication. It converts measured oxygen levels into 0–10 V, 4–20 mA, or Modbus RTU signals, while its replaceable sensor, practical design, and IP67 housing support reliable long-term operation.





Manufactured By :
EMS Control
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The OT-4XX combines oxygen sensing with an integrated display, allowing operators to view measured oxygen levels directly at the installation point. It continuously detects oxygen concentration and translates the reading into standard signals for monitoring and automation systems. A replaceable sensor simplifies maintenance, while wall- or duct-mounted configurations provide installation flexibility. With a practical enclosure and straightforward mounting, the transmitter offers a convenient approach to continuous oxygen-level supervision in monitored environments.

Specification

Supply Voltage: 12–24 V DC
Output: 0–10 V / 2–10 V / 0–3 V / 4–20 mA / 0–20 mA / Modbus RTU
OT-401 Output: 0–10 V / 2–10 V / 0–3 V
OT-441 Output: 4–20 mA / 0–20 mA
OT-461 Output: Modbus RTU
Sensor: Oxygen (O₂)
Measuring Range: 0–25% vol
Sensitivity: ±0.1% vol
Accuracy: ±1% vol
Sensor Operating Life: 2 Years
Model Product Codes: 4X1-2 / 4X1-3
Probe Options: Wall-Type Probe / Duct-Type Probe
Dimensions: 161 × 65 × 40 mm
Probe Dimensions: 115 × 24 × 24 mm
Display: Integrated display
Protection: IP67 plastic case (sensor excluded)
Sensor: Easily replaceable
