3M™ DBI-SALA® 2100185 Roof Top Freestanding Counterweight Anchor, 1 EACH

  • NG # 0799-HW-3M-053

  • MF # 2100185

The 3M™ DBI-SALA® 2100185 Roof Top Freestanding Counterweight Anchor is a non-penetrating tie-off anchor system engineered to provide a fall protection point on flat roof surfaces without damaging or drilling into the roof membrane.

Manufactured By :
3M
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Designed specifically for temporary or permanent work on flat roofs (up to a 5-degree slope), the 2100185 uses a heavy base frame and high-density counterweight plates to create a secure 5,000 lb-rated anchorage point. Because it rests entirely on the surface, it eliminates the risk of leaks or structural damage to commercial roof decks while offering 360-degree mobility for a worker tied off to its central swivel D-ring.

Specification

SpecificationDetails
Model Number2100185
Product Line3M DBI-SALA® Roof Anchor Series
Anchor TypeFreestanding Non-Penetrating Counterweight System
Max Roof Incline / PitchFlat surfaces up to 5 degrees
Working Capacity1 Person (310 lbs / 140 kg combined weight including tools)
Anchorage Point360-Degree Swivel D-Ring (5,000 lb / 22 kN rated)
Counterweight Setup16 cast iron plates (~45 lbs / 20.4 kg each)
Total Assembled Weight~720 lbs (326.5 kg) complete system
Compatible Roof SurfacesAsphalt, PVC, EPDM, TPO, Bitumen, Concrete, Smooth Decking
Materials & FinishGalvanized / powder-coated heavy steel base frame; rubber base pads
Standards & ComplianceOSHA 1910.66, OSHA 1926.502, ANSI Z359.1 requirements
