NG # 04030-HW-FST-005
MF # FST100-EC106
The FST100-EC106 EC Sensor is a high-performance digital conductivity sensor designed for continuous online water quality monitoring. Featuring an RS485 interface with Modbus RTU communication, automatic temperature compensation, and an IP68-rated stainless steel housing, it provides reliable and accurate conductivity measurements for industrial water treatment, environmental monitoring, aquaculture, and process control applications.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe FST100-EC106 EC Sensor is an intelligent electrical conductivity (EC) sensor engineered for precise conductivity measurement in a wide range of water quality monitoring applications. It supports industry-standard RS485 (Modbus RTU) communication, allowing seamless integration with PLCs, DCS systems, industrial computers, data loggers, and other automation equipment.
Designed with dual high-impedance differential amplifiers, the sensor delivers excellent anti-interference performance and rapid response even in electrically noisy industrial environments. Its automatic Pt1000 temperature compensation ensures consistent measurement accuracy across varying water temperatures.
The rugged stainless steel construction and IP68 protection rating make the sensor suitable for long-term submerged operation in pipelines, tanks, reservoirs, and open water environments. The 3/4" NPT threaded connection simplifies installation while supporting both immersion and inline mounting configurations. The FST100-EC106 is widely used in wastewater treatment, industrial process monitoring, environmental water quality assessment, aquaculture, cooling water systems, and chemical processing.
| Parameter | Specification |
|---|---|
| Product Model | FST100-EC106 |
| Sensor Type | Electrical Conductivity (EC) Sensor |
| Measurement Range | 0–2000 μS/cm, 0–20 mS/cm, 0–200 mS/cm |
| Resolution | 0.1 / 0.01 / 0.001 |
| Accuracy | ±1.5% FS, ±0.3°C |
| Temperature Compensation | Automatic (Pt1000) |
| Operating Temperature | 0°C to 50°C |
| Operating Pressure | <0.6 MPa |
| Communication Interface | RS485 |
| Communication Protocol | Modbus RTU |
| Optional Output | RS485 or 4–20 mA |
| Power Supply | 12–24 VDC |
| Power Consumption | 0.2 W @ 12 V |
| Housing Material | Stainless Steel |
| Protection Rating | IP68 |
| Installation Method | Immersion or inline installation |
| Connection Thread | 3/4" NPT |
| Calibration | Two-point or multi-point calibration |
| Compatible Equipment | PLC, DCS, Industrial PC, Controller, Data Logger, Recorder |
| Response Characteristics | Fast response with high anti-interference performance |
