Handheld DPM Code Reader SR-G100 series

  • NG # 0563018-HW-KEYENCE-018

Handheld DPM Code Reader – SR-G100 Series is a high-performance scanning solution designed for fast and stable reading of challenging 1D and 2D codes. Automatic calibration, multi-lighting control, Bluetooth connectivity, and support for difficult markings on metal and black plastic provide reliable identification in industrial applications.





Manufactured By :
Keyence
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Handheld DPM Code Reader – SR-G100 Series combines intelligent imaging with easy wireless operation to simplify code identification across demanding production environments. Its multi-lighting control automatically selects suitable illumination to reduce glare and improve readability on reflective, curved, or uneven surfaces, while automatic calibration enables quick setup with a single button. Supporting QR, DataMatrix, PDF417, and numerous 1D codes, the SR-G100 offers 0.1 mm barcode and 0.127 mm 2D-code resolution. Bluetooth communication, ergonomic handling, and IP54 protection make it a practical choice for manufacturing and traceability applications.

Specification

Type: Handheld DPM Code Reader
Model: SR-G100
Image Sensor: CMOS
Resolution: 900 × 900 pixels (2D Code); 1280 × 900 pixels (Barcode)
Light Source: High-Intensity Red LED, High-Intensity Blue LED
Supported Codes: QR, MicroQR, DataMatrix, PDF417, CODE39, CODE128, GS1-128, JAN/EAN/UPC, and more
Minimum Resolution: 0.127 mm (2D Code); 0.1 mm (Barcode)
Focal Distance: 30 mm
Wireless Communication: Bluetooth Ver. 2.1 + EDR, Class 2
Communication Distance: Approx. 10 m
Setup Communication: USB 2.0 Full Speed
Protection Class: IP54
Ambient Temperature: 0 to 45°C
Continuous Usage: Approx. 10 hours
Charging Time: Approx. 4.5 hours
Dimensions: 214 × 78.5 × 97.4 mm
Weight: Approx. 375 g
