NG # 0377205-HW-BLF-205
Balluff BAW000J is a miniature inductive distance sensor designed for precise, non-contact displacement measurement. Its compact stainless-steel housing, 0–10 V analog output, 0.5–2 mm measuring range, and IP67 protection make it suitable for demanding automation applications.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe BAW000J delivers accurate distance measurement in a remarkably compact cylindrical format, making it well suited to applications where installation space is limited. It detects positional changes without physical contact and provides a proportional analog voltage signal for easy integration with control systems. With a fast 1 kHz limit frequency, high repeat accuracy, and robust stainless-steel construction, it supports precise monitoring in automated machinery and industrial processes.
Model: BAW G06EE-UAF20B-EP03-K
Sensor Type: Inductive Distance Sensor
Operating Principle: Inductive Distance Sensor
Housing Style: D6.5, cylindrical miniature
Installation: Flush mounting
Dimensions: Ø6.5 × 30.5 mm
Measuring Range: 0.5–2 mm
Analog Output: 0–10 V
Output Characteristic: Falling on approach
Limit Frequency (-3 dB): 1000 Hz
Repeat Accuracy: ±10 µm
Maximum Non-Linearity: ±45 µm
Housing Material: Stainless steel
Sensing Surface Material: PBT
Connection: 3 m PUR cable
Operating Voltage: 21.6–26.4 V DC
Ambient Temperature: 10–60°C
Protection Rating: IP67
Approvals / Conformity: CE / UKCA / cULus / WEEE
