NG # 0377201-HW-BLF-201
Balluff BES0068 is a compact M12 inductive proximity sensor designed for reliable, non-contact detection in industrial automation. Featuring a cylindrical stainless steel housing, flush mounting, 4 mm sensing range, and PNP normally open output, it delivers precise switching performance and easy machine integration.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe Balluff BES0068 inductive proximity sensor provides dependable object detection for industrial automation and control applications. Its M12x1 cylindrical housing measures 12 × 65 mm and supports flush installation in space-constrained environments. With a 4 mm sensing range and PNP normally open switching output, the sensor enables accurate, contactless detection. Balluff's inductive sensing technology offers reliable operation, helping improve system availability while reducing maintenance requirements in demanding industrial applications.
Product Model: BES0068
Product Name: BES M12MI-PSC40B-S04G
Sensor Type: Inductive Proximity Sensor
Design: Cylindrical
Dimension: Ø12 × 65 mm
Housing Style: M12×1
Installation: Flush mounting
Sensing Range: 4 mm
Switching Output: PNP Normally Open (NO)
Switching Frequency: 2500 Hz
Housing Material: Brass, nickel-free coated
Sensing Surface Material: PBT
Connection: M12×1 male connector, 3-pin
Operating Voltage: 10–30 VDC
Ambient Temperature: -25 to +70 °C
IP Rating: IP68
Approvals/Conformity: CE, UKCA, cULus, WEEE
ECLASS: 27-27-40-01 (ECLASS 12.0–14.0)
UNSPSC: 41111926
