NG # 00100-HW-KOM-092
MF # SK715-8
Highly versatile and compact, the SK714-8 skid steer loader is the result of the competence and technology that Komatsu has acquired over the past 80 years. Developed with constant attention to the needs of customers from all around the world, the end product is a user friendly skid steer loader with top-class performances.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteA self-levelling bucket is one of the many standard features of this Komatsu skid steer loader that make it highly efficient in any application. The accelerator pedal and a 2 speed transmission further increase operator productivity. The PPC servo-controls make the SK714-8 easy to use. Natural movements and maximum precision guarantee unique efficiency and greatly contribute to reduce operator fatigue. The right joystick controls the movements of the arm and of the bucket; the left one controls the translation.
Specification
Engine
| Model | Komatsu 4D88 |
| Type | Water-cooled, 4-cycle direct injection |
| Engine power at rated engine speed | 2800 rpm |
| ISO 14396 | 34.3 kW / 46.0 HP |
| ISO 9249 (net engine power) | 32.8 kW / 44.0 HP |
| No. of cylinders | 4 |
Drives and brakes
| Type | Hydrostatic |
| No. of speeds | 2 |
| Max. travel speed | 16 km/h |
Tyres
| Standard | 10-16.5 |
| Option | 10-16.5 HD |
Hydraulic system
| Type | Komatsu CLSS |
| Hydraulic pump | Gear pump |
| Max. pump flow | 62 l/min |
| Max. operating pressure | 191 bar |
| Max. pump flow | 100 l/min |
Loader
| Operating capacity (standard bucket) | 680 kg |
| Tipping load (standard bucket) | 1360 kg |
Environment
| Engine emissions | Fully complies with EU Stage V exhaust emission regulations |
| Hand/arm | ≤ 2.5 m/s² (uncertainty K = 1.2 m/s²) |
| Body | ≤ 0.5 m/s² (uncertainty K = 0.2 m/s²) |
