PLA Liquid Level Float Switch with Alarm

  • NG # 003128-HW-IPC-028

PLA Liquid Level Float Switch detects liquid levels up to 6′ (1.8 m) with a single switch point and includes a built-in visual alarm for upset conditions. Compact with a junction box, it features NO/NC relay contacts, 2″ NPT connection, and is available in PVC, PP, PVDF, or 316 SS materials.




Manufactured By :
Icon Process Controls
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

PLA Liquid Level Float Switch with Alarm is designed for reliable liquid level detection up to 6′ (1.8 m) in industrial tanks or sumps. It includes a single switch point and an integrated visual alarm to indicate high or low level conditions. Compact and easy to install with a junction box and 2″ NPT connection, it is available in PVC, PP, PVDF, or 316 SS, offering NO/NC relay contacts for versatile control applications.

Specification

Specifications

Connection: 2″ NPT threaded process connection

Accuracy: ± 2 mm

Hysteresis: 8 mm

Alarm: Built‑in visual alarm light (high‑intensity red)

Contacts: NO or NC relay contacts

Sensor Body Materials: PVC, PP, PVDF, or 316 SS

Enclosure Material: Glass‑filled polypropylene

Protection Rating: NEMA 4X / IP67

Power Supply: 24 VDC

Minimum Switching Capacity: 60 VAC / 9 VDC

Maximum Switching Capacity: 120 VAC / 36 VDC

Operating Temp (PVC): 32 °F to 140 °F (0 °C to 60 °C)

Operating Temp (PP): −4 °F to 190 °F (−20 °C to 88 °C)

Operating Temp (PVDF): −40 °F to 240 °F (−40 °C to 115 °C)

Operating Temp (316 SS): −40 °F to 300 °F (−40 °C to 149 °C)

Suitable Liquids: Non‑viscous, non‑coating acids/bases (typical)

Approvals: CE, FCC & RoHS compliant
