NG # 00100-HW-SCH-085
MF # 00100-HW-SCH-085
SKU # 00185-HW-SCH-085
SpaceLogic™ AS-P Automation Server Compact, powerful, and versatile server, that can act as a standalone server, and also control Central I/O modules and monitor and manage field bus devices
Stock
Limited
Custom Pricing
Get A Quote
Stock
Limited
Custom Pricing
Get A QuoteThe SpaceLogic AS-P-SMK server for Smoke Control is at the core of an EcoStruxure BMS and performs key functionality. The server performs functionality such as control logic, trend logging and alarm supervision. It supports communication and connectivity to the I/O and field buses. The SpaceLogic AS-P server can act as a standalone server, control I/O modules, monitor and manage field bus devices. This model features two ethernet ports, two RS-485 ports, one LonWorks port, one I/O bus port, one USB device port and one USB host port. Its dimensions are 114 mm (4.5 in.) in height, 90 mm (3.6 in.) in width and 64 mm (2.5 in.) in depth. Plastic flame rating is UL94-5VB and the ingress protecton rating is IP20. This model is UL864 certified. A terminal base TB-ASP-W1 is required for each SpaceLogic AS-P.
| Device short name | AS-P-SMK |
| Product certifications | CULus, CE, ICES-003, FCC part 15 class B, BTL |
| Width | 90 mm |
| Product or component type | Controller |
| Communication service | SNMP network management, SMTP e-mail notification, SMTPS e-mail notification, Modbus TCP client, Modbus TCP server |
| Net weight | 321 g |
| Depth | 64 mm |
| Ambient air temperature for operation | 0…50 °C |
| IP degree of protection | IP20 |
| Flame retardance | UL94V0-5VB |
| Current consumption | 400 mA |
| Height | 114 mm |
| Ambient air temperature for storage | -20…70 °C |
| Standards | FCC CFR 47 part 15, UL 94, UL 916, UL 864 |
| Memory type | 512 MB RAM 4 GB flash |
| Product brand | Schneider Electric |
| Range | EcoStruxure Building Operation |
| Product mounting | On base, DIN rail |
| I/O limit processor capacity | 464 I/O, 29 modules |
| material | ABS/PC |
| web services | HTTP server Programmable scripts : alarm summaries, report management TLS 1.0 |
| Range compatibility | EcoStruxure Building Operation TB-ASP-W1 terminal base, EcoStruxure Building Operation TB-AS-W1 terminal base |
| Processor name | Spear 320s |
| Communication port protocol | BACnet, Modbus TCP master RS485, Modbus TCP slave RS485, HTTPS RJ45, HTTP RJ45, LON TP/FT-10 |
| Integrated connection type | USB 2.0 type A, USB type mini B |
| Relative humidity | 0…95 % |
| Unit Type of Package 1 | Db |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 11.7 cm |
| Package 1 Width | 5.7 cm |
| Package 1 Length | 9.1 cm |
| Package 1 Weight | 271.0 g |
| Unit Type of Package 2 | Doboz |
| Number of Units in Package 2 | 36 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 10.469 kg |
