600 Ø6.5 mm Embeddable Inductive Sensor

  • NG # 0522009-HW-CTRX-009

  • SKU # DW-AD-643-065

600 Ø 6.5 Embeddable 3 mm is a compact inductive proximity sensor designed for precise, non-contact detection of metallic objects in industrial automation. Featuring a 3 mm sensing range, PNP normally open output, and durable V2A stainless-steel housing, it provides reliable performance in confined installation spaces. Its IP67 protection makes it suitable for machine tools, assembly lines, robotics, and precision manufacturing.

Manufactured By :
Contrinex
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Contrinex DW-AD-643-065 operates on a 10–30 V DC supply and supports a maximum switching frequency of 3,000 Hz. It features a 6.5 mm diameter housing, a 2 m three-wire PVC cable, and an embeddable mounting design. With an operating temperature range of 0°C to +60°C and a sensor length of 35 mm, it enables dependable position detection, component verification, and automated machine control in industrial environments.

Specification

Operating range: 3 mm

Switching frequency max.: 3000 Hz

Supply voltage: 10...30 V

Polarity: PNP

Output: Normally Open (NO)

Connection: PVC, 2 m, 3 wire

Housing size: Ø 6.5 mm

Enclosure rating: IP 67

Housing material: Stainless-steel V2A

Temperature range: 0...+60°C

Sensor Height: 35 mm

Mounting: Embeddable

Interface: Standard output
