Basic Classics Series 600 – Embeddable Inductive Sensor

  • NG # 0522005-HW-CTRX-005

  • SKU # DW-AS-603-C8-001

Basic Classics Series 600 8 × 8 (C8) Embeddable 1.5 mm is a compact inductive proximity sensor designed for precise, non-contact detection of metallic objects in industrial automation. Featuring a 1.5 mm sensing range, an 8 × 8 mm housing, and IP67 protection, it delivers reliable performance in confined installation spaces. It is suitable for machine tools, assembly lines, robotics, and precision manufacturing.

Manufactured By :
Contrinex
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The DW-AS-603-C8-001 operates on a 10–30 V DC supply and supports switching frequencies up to 3,500 Hz. It features a PNP normally open output with IO-Link communication, an M8 3-pin connection, and a durable Zamak housing. With an operating temperature range of −25°C to +70°C and a 59 mm sensor height, it supports dependable position detection, component verification, and automated machine control in demanding industrial environments

Specification

Type: Inductive Proximity Sensor

Model: DW-AS-603-C8-001

Operating Range: 1.5 mm

Switching Frequency: Max. 3500 Hz

Supply Voltage: 10–30 VDC

Polarity: PNP

Output: Normally Open (NO) / IO-Link

Connection: M8, 3-Pin

Housing Size: 8 × 8 mm (C8)

Housing Material: Zamak

Protection Rating: IP67

Operating Temperature: -25 to +70°C

Sensor Height: 59 mm

Mounting: Embeddable

Interface: IO-Link
