KROHNE OPTIMASS 2000 Coriolis Mass Flow Meter

  • NG # 02953-HW-KROHNE-008

Large diameter mass flow meter developed to meet the demanding custody transfer requirements of the oil and gas industry.

Manufactured By :
KROHNE
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The KROHNE OPTIMASS 2000 coriolis mass flow meter is a large diameter instrument developed to meet the demanding custody transfer requirements of the oil and gas industry. The high performance of the OPTIMASS 2000 also makes it a suitable flow meter for the bulk measurement of petroleum and oil as well as products like syrup, molasses and raw chemicals.


KROHNE OPTIMASS 2000 coriolis mass flow meters offer excellent accuracy and repeatability for all measured values. In addition to mass flow and density measurements, the OPTIMASS 2000 also calculates volume, density, and concentration. The OPTIMASS 6000 is compatible with the KROHNE MFC 400 flow converters which can be either meter or remote mounted.


KROHNE OPTIMASS 2000 meters are designed to handle tough applications. Tube material is high grade stainless steel . The OPTIMASS 2000 is available with a wide range of options to tailor the meter to the application including a range of flange connections. A number of hazardous area approvals, calibration certificates and custody transfer approvals are available as well.

Specification

  • Large diameter for bulk measurement and custody transfer of liquids and gases
  • Stainless Steel measuring tubes (NACE Compliant)
  • Super Duplex option offering a maximum operating pressure of 180 barg
  • Innovative twin measuring tube design with large tube size, provide high flow rate capacity
  • Easily drained and easy to clean
  • Optional heating jacket
  • High accuracy for custody transfer
  • Optimized flow divider for minimum pressure loss
  • Modular electronics concept: electronics and sensor are easy to replace
  • Secondary containment up to 150 barg
