NG # 09440009-HW-SENSIRION-009
SGP41 is a digital VOC and NOx sensor designed for continuous indoor air-quality monitoring. Its dual sensing elements and Gas Index Algorithm enable reliable detection of VOC and NOx events, making it ideal for air purifiers, HVAC systems, and other air-treatment devices.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe Sensirion SGP41 combines VOC and NOx sensing in an ultra-compact 2.44 × 2.44 × 0.85 mm package. It provides a 0–500 VOC Index and NOx sensing capability, with a VOC measurement range of 0–1000 ppm and response time below 10 seconds. Its robust multi-pixel sensing element offers strong resistance to contaminating gases and long-term stability. With I²C communication, 1.7–3.6 V supply, and standard SMD assembly compatibility, the SGP41 is well suited for high-volume indoor air-quality applications.
Type: VOC and NOx Sensor
VOC Output: Digital 16-bit raw signal; 0–500 VOC Index
VOC Measurement Range: 0–1000 ppm
Response Time: <10 s
Limit of Detection: <0.05 ppm ethanol equivalents or <10% of concentration setpoint
Supply Voltage: 1.7–3.6 V
Average Supply Current: 3000 µA
Max. Supply Current: 3400 µA
Interface: I²C
Package: DFN
Dimensions: 2.44 × 2.44 × 0.85 mm
Application: Indoor Air Quality, Air Purifiers, Air Treatment Devices
