TankPro® Continuous Level Sensor Transmitter

  • NG # 003118-HW-IPC-018

TankPro® Continuous Level Sensor Transmitter is an all-in-one solution designed for accurate liquid level measurement in industrial tanks. Featuring a built-in LCD display and submersible hydrostatic sensor, it delivers ±0.5% accuracy with durable construction. Its PTFE-coated cable and Kalrez® O-rings ensure reliable performance in corrosive and demanding environments.






Manufactured By :
Icon Process Controls
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Engineered for tough industrial applications, the TankPro® Series provides continuous level monitoring for both corrosive and non-corrosive liquids. Unlike ultrasonic transmitters, it operates reliably even in the presence of foam, vapor, turbulence, or condensate. With a NEMA 4X housing, 2" NPT connection, integrally molded weight, and integrated display, it is ideal for chemical storage tanks, sumps, and industrial level monitoring systems.



Specification

Specifications

Input Pressure Range: 14 ft H₂O

Output Signal: 4–20 mA

Power Supply: 9–36 VDC

Accuracy: ±0.5% Full Scale

Stability: ±0.1% FS per year

Response Time: < 10 ms

Display: LCD Local Display

Housing Material: PVC / PP / PVDF / PTFE / 316 SS

Diaphragm: Ceramic (Al₂O₃) or 316 SS

Seal: FFKM Kalrez®

Cable: PTFE Teflon® Jacketed Cable

Protection: IP68 / NEMA 4X

Operating Temperature: −40°C to 76°C

Compliance: CE, FCC, RoHS
