ECOM Visor-Ex® 01: Industrial Grade Smart Glasses Wearables for Hazardous Areas

  • NG # 00405-HW-ECOM-006

With Visor-Ex® 01, service technicians enter a totally new world of on-site work and training. They can connect anytime to expert support and have immediate access to all relevant information.

Manufactured By :
ecom
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

With Visor-Ex® 01, service technicians enter a totally new world of on-site work and training. They can connect anytime to expert support and have immediate access to all relevant information. Both hands remain free for the work that needs to be done, while digital documents are displayed for reference and consultation.

At the same time, the technician is never left on his own and able to contact experts for audiovisual interaction anywhere and anytime. All this is accomplished by these ergonomically designed smart glasses based on well-established technologies.

Specification

Specification

CAMERA 2x central 16 MP camera and 4:3 aspect ratio with flashlight LED, notification LED, 6x optical zoom with liquid lens for fast autofocus and built-in laser (Class 1)
SCANNER Basic: QR, EAN-13, Advanced: 2D, Aztec, multiple barcodes
SENSORS 9-axis sensor (accelerometer, gyroscope, compass)
SPEAKER 85 dB loudspeaker for noisy environments
MICROPHONE Microphone array for voice commands and echo cancellation, Multilingual voice commands
DISPLAY 640 x 400 active color matrix OLED display, Touchpad
CONTRAST 1:10000
BRIGHTNESS Up to 2000 nits
BATTERY TYPE Li-Ion with 3.7 V / 4400 mAh / 16.28 Wh (built-in)
AMBIENT TEMPERATURE -20 ... +50 °C (-4 ... +122 °F)
DEGREE OF PROTECTION IP54
CONNECTION 3.5 mm jack connection (for optional headphones and microphone), Coax connection, Magnetic USB connection
WEIGHT Head Unit: approx. 180 g, Pocket Unit: approx. 300 g
DIMENSIONS Head Unit: 212 mm x 53 mm x 53 mm, Pocket Unit: 82 mm x 148 mm x 20 mm
