NG # 03298-HW-MAXO-007
In today’s rapidly advancing industrial landscape, efficient and reliable automation solutions are essential for optimizing operations. The MOXA ioThinx 4500 Series Advanced Controllers & I/Os are designed to meet these needs, providing robust, scalable, and versatile options for various industrial applications. These advanced controllers and I/Os enhance operational efficiency, making them a vital asset for modern industrial environments.
Stock
10
in stock
Custom Pricing
Get A Quote
Stock
10
in stock
Custom Pricing
Get A QuoteThe MOXA ioThinx 4500 Series is renowned for its impressive features:
Equipped with powerful processors, the MOXA ioThinx 4500 Series ensures high-speed data processing and real-time control, essential for modern industrial automation.
The modular design of these controllers and I/Os allows for easy expansion and customization, providing flexibility to meet specific application needs.
Supporting high-speed data acquisition and processing, the MOXA ioThinx 4500 enhances the efficiency and responsiveness of your industrial systems.
Built with industrial-grade materials, the MOXA ioThinx 4500 Series is designed to withstand harsh environmental conditions. The robust construction ensures long-term durability and consistent performance, making these controllers and I/Os a reliable choice for demanding industrial applications.
The installation process for the MOXA ioThinx 4500 is straightforward and user-friendly. The package includes a comprehensive step-by-step guide, minimizing setup time and effort. Required tools are minimal, allowing for quick and easy installation.
The MOXA ioThinx 4500 Series has undergone rigorous testing to ensure high performance and reliability. Users report impressive uptime and consistent operation, even in challenging industrial environments, highlighting the system’s reliability.
| Specification | Details |
|---|---|
| Isolation | 3k VDC or 2k Vrms |
| Serial Interface | |
| – Connector | Spring-type Euroblock terminal |
| – No. of Ports | 4 |
| – Serial Standards | RS-232, RS-422, RS-485-2w |
| – Baudrate | 300, 600, 1200, 1800, 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps |
| – Data Bits | 7, 8 |
| – Stop Bits | 1, 2 |
| – Parity | Even, None, Odd |
| – Flow Control | RTS/CTS (RS-232 only), XON/XOFF |
| – Pull High/Low Resistor for RS-485 | 10 kilo-ohm |
| – RS-485 Data Direction Control | ADDC® (automatic data direction control) |
| Serial Signals | |
| – RS-232 | TxD, RxD, RTS, CTS, GND |
| – RS-422 | Tx+, Tx-, Rx+, Rx-, GND |
| – RS-485-2w | Data+, Data-, GND |
| Power Consumption | |
| – System Power | 74.1 mA @ 12 VDC 37.05 mA @ 24 VDC |
| – Field Power | 140.4 mA @ 12 VDC 59.8 mA @ 24 VDC |
| Physical Characteristics | |
| – Housing | Plastic |
| – Dimensions | 26.4 x 99 x 65.5 mm (1.04 x 3.9 x 2.58 in) |
| – Weight | 115 g (0.254 lb) |
| – Installation | DIN-rail mounting |
| – Wiring | Serial cable, 18 to 24 AWG |
| – Strip Length | 9 to 10 mm |
| Environmental Limits | |
| – Operating Temperature | Standard Models: -20 to 60°C (-4 to 140°F) Wide Temp. Models: -40 to 75°C (-40 to 167°F) |
| – Storage Temperature (package included) | -40 to 85°C (-40 to 185°F) |
| – Ambient Relative Humidity | 5 to 95% (non-condensing) |
| – Altitude | Up to 2000 m |
| Standards and Certifications | |
| – EMC | EN 55032/35 |
| – EMI | CISPR 32, FCC Part 15B Class A |
| – EMS | IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m IEC 61000-4-4 EFT: Power: 1 kV; Signal: 1 kV IEC 61000-4-5 Surge: Power: 2 kV; Signal: 1 kV IEC 61000-4-6 CS: 3 V IEC 61000-4-8 PFMF |
| – Shock | IEC 60068-2-27 |
| – Vibration | IEC 60068-2-6 |
| Declaration | |
| – Green Product | RoHS, CRoHS, WEEE |
| MTBF | 916,671 hrs |
| Standards | Telcordia SR332 |
