Endress+Hauser Ultrasonic measurement Time-of-Flight Prosonic FDU90

  • NG # 006208-HW-ENDRESS-008

The Micropilot FMR30B provides accurate, maintenance-free radar level measurement with fast commissioning, Bluetooth connectivity, and compact design ideal for tight spaces and diverse utility applications.

Manufactured By :
Endress+Hauser
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

Equipped with 80 GHz technology, the FMR30B ensures reliable level monitoring in basins, rivers, sewers, tanks, silos, and stockpiles. Guided wizards simplify setup, while Heartbeat Technology enables on-demand verification and diagnostics without process interruption. With secure Bluetooth remote access and an intuitive color touch display, the device delivers efficient operation and reduced downtime across a wide range of industries.

Specification

Measuring principle

Ultrasonic

Characteristic / Application

Separated version with field housing or top hat rail housing for control cabinet instrumentation, 300m in-between sensor and transmitter

Specialities

Floating protection tube

Supply / Communication

4-wire (HART, PROFIBUS DP)

Accuracy

+/- 2mm + 0.17% of measured distance

Ambient temperature

-40 °C ... 80 °C
(-40 °F ... 176 °F)

Process temperature

-40 °C ... 80 °C
(-40 °F ... 176 °F)

Process pressure / max. overpressure limit

0.7 bar ... 4 bar abs
(10 psi ... 58 psi)

Main wetted parts

PVDF (IP68 / NEMA6P)

Process connection

Front side thread:
G / NPT 1 1/2"
Rear side thread:
G / NPT 1"
Ceiling mounting

Blocking distance

0.07 m (0.23 ft)

Max. measurement distance

Liquids: 3 m (9.8 ft),
Solids: 1.2 m (3.9 ft)

Communication

Transmitter:
4 ... 20 mA HART
PROFIBUS DP

Certificates / Approvals

ATEX, FM, CSA, IEC Ex, INMETRO, NEPSI, UK Ex

Options

Second 4...20mA output

Components

Transmitter:
FMU90, FMU95

Application limits

Foam / high turbulence possible:
FDU92
Flange-flush assembly:
FDU91F
For tank farms scanner:
FMU95

CATALOGS

Ultrasonic measurement Time-of-Flight Prosonic FDU90
