Hydrogen pressure sensor FKC-HYDROSEAL

  • NG # 03585-HW-FUJI-002

Manufactured By :
Fuji Electric
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

PRESSURE TRANSMITTER DIFFERENTIAL FOR HYDROGEN – FKC WITH HYDROSEAL MEMBRANE: DESIGNED FOR DEMANDING HIGH-HYDROGEN ENVIRONMENTS The pressure transmitter differential for hydrogen - FKC with hydroseal membrane is specifically developed to meet the challenges of measurement in hydrogen-rich environments. Thanks to its protective membrane and robust design, it ensures precise and durable measurement even in extreme industrial conditions. FEATURES OF THE PRESSURE TRANSMITTER DIFFERENTIAL FOR HYDROGEN – FKC WITH HYDROSEAL MEMBRANE - Measurement technology: differential pressure transmitter with isolated cell - Hydrogen-resistant Hydroseal diaphragm - Compatible with high-pressure and corrosive environments - High accuracy and excellent long-term stability - Chemically resistant materials APPLICATIONS Ideal for hydrogen production, distribution, or storage facilities, as well as for demanding industrial processes requiring reliable differential pressure measurement. BENEFITS Optimized design for hydrogen-containing media High reliability under severe conditions Easy integration into existing control systems Reduced maintenance costs due to diaphragm durability

Specification

LimpingL- or T-shaped housing
Measuring ranges (kPa) [e.max.]32
130
Weight per kg (without indicator)3,6
Accuracy±0.15%
Materials in contact with the processStainless steel 316, Stainless steel 316 L
Case materialsStandard: low-copper aluminum alloy with polyurethane epoxy coating (2 layers).
Option: 316 stainless steel
Membrane materialsStainless steel 316
Stability±0.15% of maximum scale for 10 years
Elevation / DeletionEqual to the upper limit of static pressure.
Process temperature-40 to +120 °C for silicone sensor filling
-20 to +80 °C for fluorinated oil sensor filling
Ambient temperaturefrom -40 to +85 °C
-20 to +80 °C for LCD indicators
- 40 to +60 °C for shutdown option
-10 to +60 °C for fluorinated oil-filled sensors
Power supply10.5 V to 45 V DC
Output signal / Load resistance4 to 20 mA
DampingConfiguration between 0.06 and 32 seconds
Zero and span adjustmentVia external sensor screw, local three-button indicator or HART™ protocol
Electrical connectionsG1/2, 1/2-14 NPT, Pg13.5 or M20 × 1.5, depending on application datasheet
OptionsIndicator, local configurator with LCD display, integrated lightning arrester, oxygen service, chlorine service, degreasing, datasheet NACE, vacuum service, optional nameplate, cell lining
