PSC-64D: Dual Display, Dual Line EC/TDS Monitor w/ 4-20mA Output

  • NG # 04255-HW-HM-014

The HM Digital PSC-64D is a compact dual‑line EC/TDS monitor designed for professional water treatment applications. It provides continuous measurement of electrical conductivity (EC) and total dissolved solids (TDS) on two separate lines with a clear dual display and standard 4‑20 mA output for system integration, offering reliable, high‑range monitoring in industrial environments.

Manufactured By :
HM Digital
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The HM Digital PSC‑64D is engineered to meet the needs of industrial and commercial water purification specialists who require precise monitoring of water quality parameters. Featuring dual simultaneous line monitoring, the device displays TDS and EC levels for both feed and product water and supports an extended measurement range suitable for various water treatment systems. Its user‑friendly design includes digital calibration, stainless‑steel electrodes, and an easy‑to‑read LCD display with backlight. The standard 4‑20 mA output allows seamless integration into broader control systems for data logging or automated response actions. The PSC‑64D includes all necessary installation components, making it ready for deployment in demanding professional environments.

Specification

  • Measurement Range: TDS 0–9999 ppm (mg/L), 0–10.0 ppt (g/L); EC 0–9999 µS/cm, 0–20.00 mS/cm
  • Accuracy: ±2 %
  • Resolution: 0–99.99: 0.1 ppm/µS; 100–9999: 1 ppm/µS; 0.1 ppt/mS
  • Automatic Temperature Compensation (ATC): Yes (1–65 °C)
  • Calibration: Digital to any point
  • Display: 2.3″ LCD with backlight
  • Output Signal: 4‑20 mA standard analog output
  • Probes: Dual stainless‑steel electrodes with 1/2″ NPTF fittings and 3 m (9.8 ft) cables
  • Power Source: AC 110 V / 220 V
  • Alarm Settings: Optional configurable alarm
  • Dimensions: 96 × 48 × 100 mm (3.8 × 1.9 × 3.9 in)
  • Weight: 261 g
