RFQ

Ubiquiti E7 Campus

  • NG # 04365-HW-UBI-004

The UniFi E7 Campus is a high-performance enterprise-grade WiFi 7 access point designed for large indoor and outdoor environments. Featuring 10 spatial streams, advanced PRISM™ RF filtering, directional high-gain antennas, and dual 10 GbE/GbE uplinks, it delivers ultra-fast wireless connectivity, reliable roaming, and support for more than 1,000 connected devices. With PoE++ support, IP-rated weather protection, and real-time spectral analysis, the E7 Campus is ideal for campuses, warehouses, stadiums, and dense enterprise deployments.

Manufactured By :
Ubiquiti Network
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Ubiquiti UniFi E7 Campus is engineered to provide enterprise-class wireless performance for demanding large-scale deployments. Built on the latest WiFi 7 standard, the device supports tri-band connectivity across 2.4 GHz, 5 GHz, and 6 GHz frequencies, enabling extremely high throughput and improved network efficiency in crowded environments. Its 10-stream architecture combines 4x4 MU-MIMO on both 5 GHz and 6 GHz bands with 2x2 MU-MIMO on 2.4 GHz, allowing simultaneous high-speed communication with numerous devices.

The E7 Campus integrates advanced PRISM™ RF filtering technology and directional internal antennas to reduce interference and improve signal quality, making it especially effective in dense wireless environments such as educational campuses, auditoriums, industrial facilities, and multi-user office spaces. The access point provides coverage of up to 465 m² (5,000 ft²) and supports over 1,000 client devices, ensuring reliable wireless connectivity across large areas.

Designed for both indoor and outdoor deployment, the device features weather-resistant construction with IPX6 protection and optional IP67 waterproofing support. Dual Ethernet ports, including a 10 GbE uplink, provide high-bandwidth backhaul and redundancy for mission-critical applications. Additional enterprise features such as fast roaming, wireless meshing, real-time spectral analysis, captive portal support, VLAN assignment, and advanced radio management help organizations build scalable and secure wireless infrastructures.

Specification

  • WiFi Standard: WiFi 7 (802.11be)
  • Spatial Streams: 10
  • Frequency Bands: 2.4 GHz, 5 GHz, 6 GHz
  • MIMO Configuration:
    • 6 GHz: 4x4 MU-MIMO
    • 5 GHz: 4x4 MU-MIMO
    • 2.4 GHz: 2x2 MU-MIMO
  • Maximum Data Rate:
    • 6 GHz: 11.5 Gbps
    • 5 GHz: 8.6 Gbps
    • 2.4 GHz: 688 Mbps
  • Coverage Area: Up to 465 m² (5,000 ft²)
  • Maximum Client Capacity: 1000+ devices
  • Ethernet Ports:
    • (1) 10 GbE RJ45
    • (1) GbE RJ45
  • Power Method: PoE++
  • Maximum Power Consumption: 44W
  • Antenna Gain:
    • 6 GHz: 12 dBi
    • 5 GHz: 12 dBi
    • 2.4 GHz: 9 dBi
  • Maximum TX Power:
    • 6 GHz: 30 dBm
    • 5 GHz: 30 dBm
    • 2.4 GHz: 23 dBm
  • RF Technology: PRISM™ RF Filtering
  • Mounting Options: Wall, Pole, Optional VESA Mount
  • Weather Protection:
    • IPX6
    • IP67 with waterproof door kit
  • Operating Temperature:
    • -30°C to 60°C
  • Enclosure Material:
    • UV-stabilized polycarbonate
    • Aluminum alloy
  • Wireless Features:
    • Wireless Meshing
    • Band Steering
    • Fast Roaming (802.11r)
    • Radio Resource Management
    • Zero-Wait DFS
    • Real-Time Spectral Analysis
    • Passpoint (Hotspot 2.0)
    • Guest Network Isolation
    • PPSK Support
    • VLAN Assignment
    • WiFi Scheduling
  • Certifications:
    • FCC
    • IC
    • NDAA Compliant
  • Software Requirement:
    • UniFi Network 9.0.114 or later
