RFQ

Ubiquiti Device Bridge Switch

  • NG # 04375-HW-UBI-014

Compact PoE+ switch* with (1) 10 GbE port, (7) 2.5 GbE ports, and 6 GHz-ready WiFi 7 bridging integration for seamless, high-capacity wireless uplink to UniFi WiFi.

Manufactured By :
Ubiquiti Network
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The Ubiquiti UniFi Device Bridge Switch (UDB-Switch) is a hybrid networking device that combines a high-performance managed PoE+ switch with an integrated Wi-Fi 7 wireless bridge. It is designed to extend high-capacity network connectivity to locations where running Ethernet or fiber cables is impractical, essentially acting as a "wireless uplink" for a cluster of wired devices.

Specification

Networking Interface(1) 10 GbE RJ45 port; (7) 2.5 GbE RJ45 ports
PoE Interface(8) PoE+ ports (up to 30W per port)
Wireless StandardWi-Fi 7 (802.11be); also supports Wi-Fi 4/5/6
Wireless Throughput6 GHz: 5.8 Gbps (320 MHz); 5 GHz: 4.3 Gbps (240 MHz)
MIMO2x2 for both 5 GHz and 6 GHz bands
Antenna Gain8 dBi (Internal)
Power Method54V DC external adapter (Included: 60W; Optional: 210W)
Max Power Consumption25W (excluding PoE output)
MountingDesktop or Wall (mount included)
Dimensions212.9 x 113 x 32.5 mm (8.4 x 4.4 x 1.3")
Weight548 g (1.21 lb)
