RFQ

Omega Digital Pressure Gauge with Rugged Housing

  • NG # 02518-HW-Omega-009

  • MF # DPG110

  • SKU # DPG110

Manufactured By :
omega
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

  • High Accuracy
  • Selectable Units of Measure
  • Selectable Relative or Sealed Measurement Reference
  • Easy to Use

Specification

Accuracy: ±0.5% BFSL (includes non-linearity, hysteresis, repeatability)
Pressure Range:
    DPG110: -14 to 100 psi
    DPG120: -14 to 1000 psi
Units of Measure: psi, bar, kg/cm², atm
Stability (1 Year): ±0.25% FS typical
Overrange Protection: 2x rated pressure
Burst Pressure: 5x or 20,000 psi, whichever is less
Pressure Cycles: 100 million cycles
Operating Temperature Range: 0 to 55°C (32 to 130°F)
Compensated Temperature Range: 0 to 55°C (32 to 130°F)
Storage Temperature Range: -40 to 65°C (-40 to 150°F)
Temperature Compensation:
    Zero: <±1.5% FS
    Span: <±1.5% FS
Pressure Sensor Connection: 1/8 FNPT
Update Rate: 3 samples per second
Wetted Parts: Stainless steel
Power: 9 V alkaline battery (included)
Auto Shut-Off: 1 hr
Battery Life: 100 hr continuous operation
Dimensions: 101 H x 63 W x 44 mm D (4 x 2.5 x 1.75")
Weight: 0.16 kg (0.36 lbs)
