MV210 Full-Featured High-Power Converter with Graphics Display

  • NG # 08615-HW-FMS-0615

FLOMOTION MV210 Electromagnetic Flow Meter Converter is a high-power converter designed for connection to all ISOMAG® sensors in water, wastewater, and demanding industrial applications. Its high-power coil excitation delivers improved performance in low-conductivity fluids or applications with higher solids content, ensuring stable and accurate measurement.



Manufactured By :
FLOMOTION SYSTEMS
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

MV210 Features include ±0.2% of reading accuracy, keypad or PC programming via Mini-B USB, flexible mounting for top or front viewing, and full galvanic isolation between inputs, outputs, and power supply. It offers NEMA 6 (IP67) protection (IP68 available upon request), bidirectional measurement, batching functions, low flow cut-off, empty pipe detection, alarm limits, and a large back-lit LCD with protective cover.

Specification

SPECIFICATIONS

• Accuracy to ±0.2% of rate

• Repeatability: ± 0.2%

 • Ambient Temperature -4 to 140ºF (Aluminum Housing) -4 to 104ºF (Nylon Housing)

• Humidity Range: 0-100%

 • Environmental Rating: NEMA 6 / IP67

• Fluid Conductivity: 5 µS (min, compact mount)

• Power Supply Options: 12-48VDC or 100-240 VAC. 44-66Hz. 1.5w sensor only, 5w all loads.

• 4-20mA output maximum load: 1000Ω, 24VDC.

 • Inputs/outputs are galvanically isolated from power supply up to 250 V

• USB cable type A/USB MINI B required for PC programming

• Values stored in memory in case of power failure

• Graphic display 128x64 pixels w/back light

• 3 external programming keys

• Digital Outputs, 1250 Hz, 100mA, 30 Vdc (max)

• MicroSD Memory Card 4 - 32 GBytes

• Cable glands - PG11

 • Max cable length between sensor and converter: 330ft (1640 ft. with preamp, conductivity >200mS/cm)
