Pepperl + Fuchs Retroreflective Photoelectric Sensor, Block Sensor, 12 m Detection Range

  • NG # 03010-HW-PEP-030

  • MF # RLK29-55/59/116-SET

Pepperl+Fuchs retroreflective photoelectric block sensors with a 12-meter detection range (such as the popular RL31-54 and RLK31-54 series) are designed for long-range material handling, conveyor positioning, and industrial door monitoring applications.

Manufactured By :
Pepperl+Fuchs
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

These 12 m block sensors feature an integrated polarizing filter. The sensor emits polarized light, and the corner-cube reflector rotates the light's polarization axis by 90° before returning it. This prevents shiny or reflective targets (such as plastic wrap, stainless steel cans, or wet surfaces) from tricking the sensor into thinking the path is unblocked.

Specification

ParameterTechnical Specification
Sensing Range / Operating Distance0 – 12 m (when paired with standard reflector, e.g., C110-2 or H85-2)
Light SourceVisible Red LED (630 nm – 660 nm) with polarization filter
Housing StyleRectangular Block (Compact / Mid-size industrial design)
Supply Voltage ($U_B$)

DC Models (RL31): 10 – 30 V DC


AC/DC Models (RLK31): 24 – 240 V AC / 12 – 240 V DC

Output Type Options

RL31: Push-Pull (PNP/NPN selectable) or dual PNP/NPN


RLK31: Relay output (SPDT SPST contact)

Switching ModeLight-ON / Dark-ON (Selectable via DIP switch or wiring)
Response Time$\le 0.5\text{ ms}$ (DC models) / $\le 20\text{ ms}$ (Relay output variants)
Switching Frequency ($f$)Up to 1,000 Hz (DC variants)
Housing MaterialPolycarbonate / ABS high-impact plastic
Optical Face MaterialPMMA plastic lens
Ambient Operating Temperature-30 °C to +60 °C (-22 °F to +140 °F)
Protection DegreeIP67 (Dust-tight and water immersion resistant)
Connection OptionsM12 4-pin quick-disconnect plug, or 2 m integrated PVC cable
