Black Box KVXHP-200 - KVM / audio / serial / USB extender - RS-232, USB 2.0, 10 GigE, DisplayPort, 5 GigE

  • NG # 03474-HW-BLACK-007

  • MF # KVXHP-200

Manufactured By :
Black Box

Stock
10 in stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Need Help Ordering?
Call +88 01714243446

Stock
10 in stock

Custom Pricing

Get A Quote

Overview

The KVX HP Series Extenders are high-performance KVMA (keyboard, video, mouse, audio) extenders. Ultra-high-definition (UHD) 4K60 video, USB 2.0, and audio are transmitted on a single CATx or fiber cable. Developed for enterprise organizations and high-pressure control rooms, it combines the simplicity of true plug-and-play and high-performance 4K KVM extension. In a point-to-point configuration, the single-head models enable you to locally use a DisplayPort monitor, USB keyboard/mouse/ other devices, speaker and microphone to operate a remote computer, server, or other IT device. The dual-head models enable you to use two DisplayPort monitors. The quad-head models support four DisplayPort monitors. Operation is plug-and-play.

Specification

General
Device Type
KVM / audio / serial / USB extender
Form Factor
Desktop
Networking
Data Link Protocol
RS-232, USB 2.0, 10GbE, DisplayPort, 5GbE
Keyboard / Mouse Interface
USB
Max Resolution
4096 x 2160 @ 60 Hz
Max Transfer Distance
2.5 miles
Dimensions & Weight
Width
7.3 in
Depth
5.8 in
Height
1.5 in
Weight
2.84 lbs
Environmental Parameters
Min Operating Temperature
32 °F
Max Operating Temperature
104 °F
Humidity Range Operating
0 - 80%
