Black Box USB-Powered - switch - 8 ports

  • NG # 03498-HW-BLACK-031

  • MF # LBS008A

Manufactured By :
Black Box

Stock
10 in stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Need Help Ordering?
Call +88 01714243446

Stock
10 in stock

Custom Pricing

Get A Quote

Overview

This compact portable Fast Ethernet switch enables easy network expansion and can be powered from a USB port. Autosensing 10-/100-Mbps ports. Autonegotiating half-/full-duplex. Auto-MDI/MDI-X function on all ports so no need for cross-pinned cables. Non-blocking store-and-forward switching method. Easy-to-see LED indicators enable you to view network status. Easy plug-and-play operation. Compact so you can tuck it neatly in the back of your PC.

Specification

General
Device Type
Switch - 8 ports
Enclosure Type
Desktop
Subtype
Fast Ethernet
Ports
8 x 10/100
MAC Address Table Size
1K entries
Features
Flow control, auto-sensing per device, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, USB powered
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Status Indicators
Power, link/activity
Expansion / Connectivity
Interfaces
8 x 100Base-TX RJ-45
Power
Power Device
External power adapter
Voltage Required
AC 120 V (60 Hz)
Miscellaneous
Cables Included
1 x USB adapter
Compliant Standards
RoHS
Dimensions & Weight
Width
3.1 in
Depth
2.4 in
Height
0.8 in
Manufacturer Warranty
Service & Support
Limited warranty - 1 year
Environmental Parameters
Min Operating Temperature
32 °F
Max Operating Temperature
131 °F
Humidity Range Operating
10 - 90% (non-condensing)
