NG # 03687-HW-IFM-014
Optical distance measurement in the micrometre range Two switching outputs
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteSuitable for high-frequency applications Three operating modes and a robust, compact design enable a wide range of applications
| Type of light | red light |
| Laser protection class | 1 |
| Housing | rectangular |
| Operating voltage[V] | 18...30 DC; ("supply class 2" to cULus) |
| Current consumption[mA] | < 30 |
| Protection class | III |
| Reverse polarity protection | yes |
| Power-on delay time[s] | < 0.3 |
| Type of light | red light |
| Wave length[nm] | 630 |
| Typ. lifetime[h] | 50000 |
| Number of inputs and outputs | Number of digital inputs: 1; Number of digital outputs: 1; Number of analogue outputs: 1 |
| Inputs | Laser On/ Off |
| Number of digital inputs | 1 |
| Total number of outputs | 2 | |
| Electrical design | PNP/NPN; (parameterisable) | |
| Number of digital outputs | 1 | |
| Output function | normally open / normally closed; (parameterisable) | |
| Max. voltage drop switching output DC[V] | 2.2 | |
| Permanent current rating of switching output DC[mA] | 100 | |
| Switching frequency DC[Hz] | 200 | |
| Notes on switching frequency[Hz] |
| |
| Number of analogue outputs | 1 | |
| Analogue current output[mA] | 4...20; (IEC61131-2) | |
| Max. load[Ω] | 500 | |
| Analogue voltage output[V] | 0...10; (IEC 61131-2) | |
| Min. load resistance[Ω] | 5000 | |
| Short-circuit protection | yes | |
| Overload protection | yes |
| Range adjustable | yes |
| Max. light spot diameter[mm] | 0.5 |
| Light spot dimensions refer to | at maximum range |
| Measuring range[m] | 0.03...0.08; (6...90% remission) |
| Temperature compensation | yes |
| Repeatability[mm] | 0.03 |
| Linearity error of analogue output[%] | ±0,1 |
| Resolution[mm] | 0,01 |
| Notes on the accuracy / deviation | The indicated values are reached after a warm-up time of 20 minutes. |
| Parameter setting options | hysteresis / window / 2-point; Switch-on and switch-off delay; switch-on operations; Teach function; filter; light-on/dark-on mode; laser switch-off; Type of operation |
| Communication interface | IO-Link | ||||||||||||
| Transmission type | COM2 (38,4 kBaud) | ||||||||||||
| IO-Link revision | 1.1 | ||||||||||||
| SDCI standard | IEC 61131-9 | ||||||||||||
| Profiles |
| ||||||||||||
| SIO mode | yes | ||||||||||||
| Required master port type | A | ||||||||||||
| Min. process cycle time[ms] | 3.2 | ||||||||||||
| IO-Link process data (cyclical) |
| ||||||||||||
| IO-Link functions (acyclical) | application specific tag; operating hours counter | ||||||||||||
| Supported DeviceIDs |
| ||||||||||||
| Note |
|
| Ambient temperature[°C] | 0...60 |
| Storage temperature[°C] | -10...65 |
| Protection | IP 65; IP 67 |
| EMC |
| ||||||||||||
| Vibration resistance |
| ||||||||||||
| Shock resistance |
| ||||||||||||
| Laser protection class | 1 | ||||||||||||
| Notes on laser protection |
| ||||||||||||
| MTTF[years] | 552 | ||||||||||||
| UL approval |
|
| Weight[g] | 127.2 |
| Housing | rectangular |
| Dimensions[mm] | 51 x 51 x 17 |
| Materials | housing: diecast zinc; front pane: plastics |
| Tightening torque[Nm] | 5 |
| Display |
| ||||||
| Teach function | yes |
| Pack quantity | 1 pcs. |
| Connection | Connector: 1 x M12; coding: A |
