RK500-04 Type-B Dissolved Oxygen(DO) Sensor

  • NG # 04316-HW-RIK-005

The RK500-04 Type-B Dissolved Oxygen (DO) Sensor is a high-performance water quality monitoring device designed for accurate and real-time measurement of dissolved oxygen and temperature in various aquatic environments. Utilizing advanced fluorescence technology, it delivers fast response, high precision, and long-term stability, making it suitable for industrial, environmental, and aquaculture applications.

Manufactured By :
Rika Sensor
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

The RK500-04 Type-B Dissolved Oxygen Sensor is engineered to provide reliable and continuous monitoring of dissolved oxygen levels in water-based systems. Built on a fluorescence measurement principle, the sensor ensures accurate detection of oxygen concentration with minimal interference from environmental factors. Its robust stainless steel construction enhances durability, allowing it to operate effectively in demanding industrial and environmental conditions.

This sensor integrates both dissolved oxygen and temperature measurement, enabling comprehensive water quality analysis in a single device. With its fast response time and high sensitivity, it is capable of delivering real-time data for process control and monitoring applications. The device is designed for easy installation, supporting both pipeline and submersible mounting, and features an IP68 rating for full water immersion.

Widely used in industries such as water treatment, aquaculture, environmental monitoring, and chemical processing, the RK500-04 ensures consistent performance with low drift and minimal maintenance. Its compatibility with RS485 and 4–20mA outputs allows seamless integration into modern control systems, making it a reliable solution for continuous dissolved oxygen monitoring.

Specification

  • Model: RK500-04 Type-B
  • Measurement Parameters: Dissolved Oxygen (DO), Temperature
  • DO Range: 0–20 mg/L (optional up to 0–50 mg/L)
  • Temperature Range: 0–60°C
  • DO Accuracy: ±0.2 mg/L
  • Temperature Accuracy: ±0.5°C
  • Resolution: 0.01 mg/L (DO), 0.1°C (Temperature)
  • Repeatability: 0.05 mg/L
  • Response Time: T90 < 40 seconds
  • Stability: Drift < 0.2 mg/L per year
  • Measuring Principle: Fluorescent method
  • Temperature Compensation: Thermal resistance
  • Output Signal: RS485 and 4–20mA (simultaneous)
  • Power Supply: 7–30 VDC
  • Power Consumption: < 0.2W
  • Material: 316L Stainless Steel
  • Protection Rating: IP68 (submersible)
  • Operating Temperature: -5°C to +60°C
  • Storage Temperature: -20°C to +80°C
  • Working Pressure: Up to 0.8 MPa
  • Installation Method: Pipe or immersion (dip) mounting
  • Thread Type: NPT 3/4 (upper and lower)
  • Cable Length: 5m (customizable)
  • Weight: Approximately 0.7 kg
