Differential pressure sensor FKC - FCX-AIV V6 Series

  • NG # 03584-HW-FUJI-001

Manufactured By :
Fuji Electric

Stock
10 in stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Need Help Ordering?
Call +88 01714243446

Stock
10 in stock

Custom Pricing

Get A Quote

Overview

DIFFERENTIAL PRESSURE TRANSMITTER – FKC : ACCURACY AND RELIABILITY FOR YOUR INDUSTRIAL PRESSURE MEASUREMENTS The differential pressure transmitter FKC from Fuji Electric is designed to provide optimal accuracy in pressure measurement across various industrial environments. Robust and reliable, it is suitable for applications requiring precise differential pressure control, ensuring efficient process management. FEATURES OF THE DIFFERENTIAL PRESSURE TRANSMITTER – FKC - High measurement accuracy thanks to silicon micro-machined sensor technology - Wide pressure range available to meet different industrial needs - Excellent long-term stability, reducing calibration requirements - Robust design with resistance to harsh environments - Integrated HART digital communication for easy system integration - ATEX-certified for hazardous areas - Compliance with SIL2 / SIL3 safety integrity levels APPLICATIONS The FKC differential pressure transmitter is used in industries such as petrochemicals, energy, water treatment, and food processing to monitor and regulate processes with high precision. ADVANTAGES Increased reliability thanks to robust design and excellent long-term stability Versatility with a wide range of pressure levels and configurations Guaranteed safety with certifications for demanding environments Reduced maintenance costs due to low drift and minimal calibration needs

Specification

HousingL- or T-shaped housing
Measuring ranges (kPa) [e.max.]1
6
32
130
500
3000
20000
Weight per kg (without indicator)3,1
Accuracy± 0.065% of the measurement range set as standard.
An accuracy of ±0.04% is also available as an option.
Materials in contact with the processStainless steel 316 L, Hastelloy-C, Monel, Tantalue, Stainless steel 316 L + Gilding, Monel coating, Tantalue coating
Case materialsLow-copper aluminum alloy with polyester coating, or 316 L stainless steel
Membrane materialsStainless steel 316 L
Hastelloy-C
Monel
Tantalum
Stainless steel 316 L and Gilding
Gilding and Ceramics
Stability±0.1% of maximum scale for 10 years for digit
6 = 3, 5, 6, 8 and 9.
Elevation / DeletionFrom -100 to +100% of maximum scale
Scale setting range1 to 1/100 of maximum scale
Measurement cycle40 ms
Communication protocolHARTTM 7 communication protocol
Process temperatureFrom +40° to +120°C (versions for higher temperatures are available)
Ambient temperatureFrom -40° to +85 °C
Power supply10.5 to 45 V DC
Output signal / Load resistance4-20 mA / 250 Ω typical
DampingConfigurable between 0.04 and 32 secs
Zero and span adjustmentVia external sensor screw, local three-button display or HARTTM protocol
Electrical connectionsM20x1.5" / 1/2 - 14 NPT / Pg13.5
OptionsDigital indicator, degreasing treatment, oxygen service, chlorine service, additional stainless steel identification plate
