Compact, Low Pressure Transducers for Clean Gases PX142-030D5V

  • NG # 03876-HW-Omega-047

Manufactured By :
omega
Ask For Price

Stock

Need Help Ordering?
Call +88 01714243446

Custom Pricing

Get A Quote
Ask For Price
Need Help Ordering?
Call +88 01714243446

Stock

Custom Pricing

Get A Quote

Overview

This is a differential pressure sensor designed for accurate measurement of non-corrosive gases such as Argon, Carbon dioxide, Helium, Hydrogen, Nitrogen, and Oxygen. It offers a fast response time of 1 ms and high precision with an accuracy of ±0.75% and minimal thermal effect on span (0.01% FS/°F). The sensor operates within a pressure range of 0–30 psi and is compensated for temperatures between -18 °C and 63 °C.

Specification

Accuracy± 0.75 %
Accuracy Class> 0.25%
Additional Features 1None
Burst Pressure3x Full Scale
Compensated Temperature, Max63 °C
Compensated Temperature, Min-18 °C
Electrical ConnectionPins
Electrical Output1 to 6 V
Electrical Output Note1 to 6 Vdc (± 2.5 Vdc PX143)
Hysteresis0.15% FS (0.30% FS ≤5 psi range)
Linearity Error± 0.75%
Measurement Pressure TypeDifferential
Measurement Pressure, Max30 psi
Measurement Pressure, Min0 psi
Media CompatibilityArgon, Carbon dioxide, Helium, Hydrogen, Nitrogen, Non-corrosive Dry Gasses, Oxygen
Output SignalVoltage
Process Connection Size5 mm
Process Connection TypeStem
Response Time1 ms
Supply Voltage8 Vdc
Thermal Effect on Span error, Max0.01% FS/°F
Zero/Balance Error1.0 Vdc ± 0.05
Zero/Balance Error Note1 Vdc ± 0.05 (3.5 ± 0.05 Vdc PX163 Series)
