NG # 04152-HW-PEP-035
MF # NBB4-12GM30-E2-V1
The ML100-54-F/103/115b is a compact retroreflective photoelectric sensor designed for precise object detection in industrial automation. It features a visible red LED light source, a detection range up to 2.7 m, and adjustable switching modes. With IP67 protection and a robust housing, the sensor delivers reliable performance in harsh industrial environments.
Stock
Custom Pricing
Get A Quote
Stock
Custom Pricing
Get A QuoteThe ML100-54-F/103/115b retroreflective photoelectric sensor from Pepperl+Fuchs is designed for reliable object detection in industrial automation systems. This compact optical sensor uses modulated visible red LED light and a reflector to detect objects with high precision. It features adjustable sensitivity and configurable light-on/dark-on switching, allowing flexible installation in various automation environments.
With a detection range of up to 2.7 meters and a fast response time of 0.5 ms, the sensor ensures quick and accurate switching operations in high-speed applications. The device operates on a 10–30 V DC supply and includes a protected PNP output with short-circuit and reverse polarity protection for safe and stable performance.
The ML100 series sensor is built with a durable polycarbonate housing and PMMA optical surface, offering reliable performance even in demanding industrial environments. With an IP67 protection rating and a wide operating temperature range, it can withstand dust, moisture, and temperature variations commonly found in manufacturing and automation processes. This sensor is ideal for conveyor systems, packaging machines, material handling systems, and other industrial detection applications.
· Product Type: Retroreflective photoelectric sensor
· Brand: Pepperl+Fuchs
· Model: ML100-54-F/103/115b
· Detection Range: 0 to 2.7 m
· Threshold Detection Range: Up to 3 m
· Reflector Distance: 0.02 to 2.7 m
· Light Source: LED
· Light Type: Modulated visible red light
· Polarization Filter: Yes
· Light Spot Diameter: Approx. 200 mm at 3 m distance
· Opening Angle: Approx. 4°
· Operating Voltage: 10 to 30 V DC
· No-Load Supply Current: < 20 mA
· Output Type: 1 PNP output (open collector)
· Switching Voltage: Maximum 30 V DC
· Switching Current: Maximum 100 mA
· Voltage Drop: ≤ 1.5 V DC
· Switching Frequency: 1000 Hz
· Response Time: 0.5 ms
· Operating Temperature: −30 °C to +60 °C
· Storage Temperature: −40 °C to +70 °C
· Degree of Protection: IP67
· Housing Material: Polycarbonate (PC)
· Optical Surface Material: PMMA
· Dimensions: 11 mm × 31 mm × 20 mm
· Connection: 300 mm fixed cable with 4-pin M12 connector
· Weight: Approx. 20 g
· Compliance Standard: EN 60947-5-2
· Certifications: cULus Listed, EAC conformity
